Strong & Cost Effective Square Tube Strongbacks
Silverback Strongbacks are completely modular adjustable pipe supports systems designed for hanging MEP pipe. Square tubes support your pipes with the strength of structural steel, but without any of the hassle of fabrication.
Our Silverback Strongback adjustable pipe supports can be installed up to five times faster than traditional, fabricated steel supports because they require absolutely no welding, grinding, hole-drilling, cutting, or painting field adjustments necessary!
A wide variety of pipe supports and hangers can be attached directly to the square tubing supports. Even more versatility can be achieved by mounting strut channel to our Silverback Strongback Pipe Supports to increase the variety of pipe and conduit clamps that can be affixed to include strut mounted pipe clamp options.
Silverback Strongbacks Key Benefits
- Weight Loading up to 10,000 lbs
- Utilizes Standard All Thread from 1/2″ to 1″
- Assembled by a Visually Impaired Person
- All Hardware is Electro-Galvanized
- Tubing Sections are Pre-Galvanized or Hot Dip Galvanized
- Bracketry is Hot Dip Galvanized
- Project Takeoff & Quote Available
Strong, Versatile Strongback Pipe Hangers
Silverback Strongback pipe supports for mechanical, electrical and plumbing applications utilize heavy-duty fabricated steel brackets, standard hardware and square tubes, supported by threaded rod. Versatile, four-sided square tubing allows for a variety of pipe support brackets and pipe support configurations.
12 Gauge Supports (Available in 4′, 6′, & 8′ Lengths)
*also available in 10′ Lengths with midspan drop support
Silverback Strongback Pipe Support: SB-150 utilizes 1-1/2″ Square Tube Sections
Silverback Strongback Pipe Support: SB-175 utilizes 1-3/4″ Square Tube Sections
Silverback Strongback Pipe Support: SB-200 utilizes 2″ Square Tube Sections
Silverback Strongback Pipe Support: SB-225 utilizes 2-1/4″ Square Tube Sections
Silverback Strongback Pipe Support: SB-250 utilizes 2-1/2″ Square Tube Sections
10 Guage Pipe Supports (Available in 4′, 6′, 8′, & 10′ Lengths)
Silverback Strongback Pipe Support: SB-219 utilizes 2-3/16″ Square Tube Sections
Silverback Strongback Pipe Support: SB-250 utilizes 2-1/2″ Square Tube Sections
* All above supports (with the exception of the SB-150) can be further strengthened by the addition of interior telescoping tubing supports that slide directly inside the main support tubes.
* Addition of midspan drop support improves deflection
* Contact us for seismic designs
Click To: Download the SB-200 Product Specifications (still need to update link w/ new submittal)
Strongback Construction Applications
- Water Supply Lines
- Gas Lines
- Mechanical Piping
- Electrical Conduit
- Condensate Pipe
- Refrigeration Lines
- and More
